Specifications available as a download

Important notice The information displayed below this paragraph is for reference purposes only. The information may be generic in nature, which covers the entire range of products that fall within this category, and might not apply to this specific model. Please select the correct model as per the above description.

Kindly note that additional software, such as anti-virus and office software, are trial versions and a license will need to be purchased to use the software without limitations.

Overview:

Archer C24 - AC750 Dual-Band Wi-Fi Router

• High-Speed Wi-Fi-AC750 dual-band is ideal for HD video streaming, high-speed downloading.
• Far-Reaching Coverage-4x antennas deliver far-reaching Wi-Fi and reliable connections.
• Multi-Mode 3 in 1-Supports Router, Access Point, and Range Extender to add flexibilities.
• Parental Controls-Manages when and how connected devices can access the internet.
• Guest Network-Provides separate access for guests while securing the host network.
• Smooth HD Streaming -Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming.
• IPv6 Supported -Compatible with the IPv6 (the latest Internet Protocol version 6).
• Compact and Mountable-Designed to conserve space and complement any decor.

Features:

Doubling Bandwidth with Dual Band
AC Dual-band WiFi allows you to connect your demanding devices to the faster and clearer 5 GHz band, while a tradition 2.4 GHz
band provides a far-reaching, stable connection to the rest of your devices.

• 433 Mbps 5 GHz Band 5 GHz Faster and clearer Wi-Fi ensures smooth 4K streaming
• 300 Mbps 2.4 GHz Band 2.4 GHz Wall-Penetrating signal covers the whole apartment*

Stable and Far-Reaching
Featuring 4x diagonally-distributed antennas, Archer C24 cover more direction and expand the WiFi coverage,
supporting buffer-free surfing and stalling-free downloading.

Multi-Mode 3 in 1

• InternetArcher C24Router Mode (Default) Plug in an Ethernet cable to instantly create a private wireless network and share internet access with all your Wi-Fi devices.
• InternetHost RouterArcher C24Access Point Mode Transform your existing wired network into a wireless one.
• InternetHost RouterArcher C24Range Extender Mode Boost the existing wireless coverage in your house.

Versatile Management
Easily manage your home network with versatile built-in tools, including Parental Controls, Guest Network, QoS, and more.

• Parental Controls Block content Limit online time
• Guest Network Use a different password Secure private network
• QoS Prioritize devices
• High Priority
• Standard Priority
• Standard Priority
• Parents
• Children
• Guests
• 20:00
• Study time
• 18:00
• IPv6 Supported
• IPTV Supported
• Easy Wi-Fi Sharing
• LED Control

High Integration, Compact Size
Archer C24's system structure focuses on creating optimal WiFi. The advanced semiconductor technology helps integrate units including CPU, memory, and a 3-stream processing unit onto a single chip to achieve high compatibility, bringing you the same power with a compact design.

As Stable as a Larger One
Archer C24 goes through rigorous repeated testing to ensure a final product reliable under a number of strenuous environments. The final result: 8 randomly selected Archer C24 routers collectively tested for 1,936 hours.

• Continuous Transmission Test : 24 h (Continuous 10 GB file uploads and downloads.)
• Structure Test : 1.5 m + 120 min (Drop impact test from 1.5 m height and a 120 min vibration test.)
• Harsh Environment Test : 48 h (Storage temperature: 60 °C and -40 °C.)
• RAM Stress Test : ≥ 25,000 (Read and write combined.)
• Capacity Test : 16 devices + 7 days (16 connected Wi-Fi devices continuously streaming for 7 days without dropping WiFi.)
• Flash Test : ≥ 2,000 I/O (Read and write combined.)

Easy Setup at Your Fingertips
Set up Archer C24 in minutes via its intuitive web interface or the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device.

Specifications:

©2026 Respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC (//www.comx-computers.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	ARCHER-C24
WIRELESS
Standards	Wi-Fi 5
	IEEE 802.11ac/n/a 5 GHz
	IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds	AC750
	5 GHz: 433 Mbps (802.11ac)
	2.4 GHz: 300 Mbps (802.11n)
WiFi Range	2 Bedroom Houses
	4x Fixed Antennas
	Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity	Medium
	Dual-Band
	Allocate devices to different bands for optimal performance
Working Modes	Router Mode
	Access Point Mode
	Range Extender Mode
HARDWARE
Processor	Single-Core CPU
Ethernet Ports	1x 10/100 Mbps WAN Port
	4x 10/100 Mbps LAN Ports
Buttons	WPS/Reset Button
Power	9 V ⎓ 0.6 A
SECURITY
WiFi Encryption	WEP
	WPA
	WPA2
	WPA/WPA2-Enterprise (802.1x)
Network Security	SPI Firewall
	Access Control
	IP & MAC Binding
	Application Layer Gateway
Guest Network	1x 5 GHz Guest Network
	1x 2.4 GHz Guest Network
SOFTWARE
Protocols	IPv4
	IPv6
Parental Controls	URL Filtering
	Time Controls
WAN Types	Dynamic IP
	Static IP
	PPPoE
	PPTP
	L2TP
Quality of Service	QoS by Device
NAT Forwarding	Port Forwarding
	Port Triggering
	DMZ
	UPnP
IPTV	IGMP Proxy
	IGMP Snooping
	Bridge
	Tag VLAN
DHCP	Address Reservation
	DHCP Client List
	Server
DDNS	NO-IP
	DynDNS
Management	Tether App
	Webpage
	Check Web Emulator>
PHYSICAL
Dimensions (WxDxH)	4.5 x 4.2 x 1.0 in
	(115 x 106.7 x 24.3 mm)
Package Contents	Wi-Fi Router Archer C24
	Power Adapter
	RJ45 Ethernet Cable
	Quick Installation Guide
OTHER
System Requirements	Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
	Cable or DSL Modem (if needed)
	Subscription with an internet service provider (for internet access)
Certifications	FCC, CE, RoHS
Environment	Operating Temperature: 0°C~40°C (32°F ~104°F)
	Storage Temperature: -40°C~60°C (-40°F ~140°F)
	Operating Humidity: 10%~90% non-condensing
	Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power	CE:
	<20dBm(2.4GHz)
	<23dBm(5GHz)
WiFi Reception Sensitivity	5GHz:
	11a 54M: -76dBm
	11ac VHT20 MCS8: -71dBm
	11ac VHT40 MCS9: -66dBm
	11ac VHT80 MCS9: -62dBm
	2.4GHz:
	11g 54M: -76dBm
	11n HT20 MCS7: -73dBm
	11n HT40 MCS7: -71dBm
