Overview:

Turn Everywhere 4G into Speedy AC1200 Wi-Fi
With 4G Cat. 4 standards, LT500 Outdoor communicates with a 4G tower with speeds of up to 150 Mbps download and 50 Mbps upload. With MU-MIMO and dual-band features, the AC1200 Wi-Fi shares the fast 4G with over 30 devices while minimizing the latency.

Boosted Wi-Fi Coverage with Beamforming
Tested Wi-Fi coverage performance in four different scenarios, achieved by Beamforming technology and two built-in antennas. If your space is too large for one Cudy 4G Outdoor Router to cover, you can expand your Wi-Fi coverage into a Mesh network by adding another Cudy AP.

Insert a SIM, Enjoy Wi-Fi
Install Wi-Fi anywhere is as easy as plugging a SIM card and booting it up with the PoE adapter. One PoE Adapter is included in the box.

Pull Network to 100 m Away
Plug your Ethernet cable into the PoE adapter/switch to get up to 100 m of wired network reach. The extra cable is not included in the box.

Install an AP for Indoor Wi-Fi
Connect an AP to the PoE adapter to equip your cafe, home, or office with a better Wi-Fi signal. AP needs to bepurchased separately.

Install Extension Antennas
The default 4G antennas are as sensitive as a standard phone's antennas. You can still replace them with customized ones via the SMA connectors.

Specifications:

©2026 Respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC (//www.comx-computers.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	CD-LT500O
Model	LT500-Outdoor
LTE Module Model EU Version	EC200A
	LTE-FDD: B1/B3/B5/B7/B8/B20/B28
	LTE-TDD: B38/B40/B41
	WCDMA: B1/B5/B8
	GSM/EDGE: B3/B8
LTE Module Model US Version	EC25-AFXD
	LTE-FDD: B2/B4/B5/B12/B13/B14/B66/B71
	WCDMA: B2/B4/B5
Flash	128 Mbit (16 MB) SPI Flash
DDR	1 Gbit (128 MB) DDR
Interface	1 x 10/100 Mbps WAN/LAN RJ45 Port (24V/0.5A passive PoE, 4 / 5+, 7/8-)
	1 x Reset Button
	1 x Nano SIM Slot
LED	System/Internet/Ethernet/2.4G WiFi/5GHz WiFi/Signal Strength
Antenna	2 x Internal Wi-Fi Antennas
	2 x External Detachable 4G Antennas
Wireless Features
Wireless Standards	IEEE 802.11 ac/a/n/b/g
Frequency	2.4 GHz, 5 GHz
Signal Rate	867 Mbps (5 GHz), 300 Mbps (2.4 GHz)
	Compatible with 802.11ac/a/b/g/n Wi-Fi standards
Transmit Power	CE: <20dBm
	FCC:<30dBm
Wireless Modes	Enable/Disable Wireless Radio, WMM
Wireless Security	WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Software Features
WAN Type	4G/Dynamic IP/Static IP/PPPoE
DHCP	Server, DHCP Client List, Address Reservation
Dynamic DNS	Compatible with 15 more DDNS providers
NAT	Port Forwarding, Port Triggering, UPnP, DMZ
VPN Sever & Client	PPTP / L2TP / OpenVPN / WireGuard / IPSec / Zerotier
CWMP Protocol	TR069 / TR098 / TR111 / TR181
ACS Server Compatibility	GenieACS, OpenACS
Management	Access Control, Local Management, Remote Management, Wake on LAN
TTL	Extend/Spoof/Custom
DNS	Cloudflare/Google/Custom
Internet Protocols	IPv4 / IPv6
IPv6	Relay
	Dynamic(SLAAC/DHCPv6)
	Static (Fixed IP)
	Passthrough
	MAP-E (Dual-stack)
	DS-Lite (Dual-stack)
SMS	Send/Receive
4G Band Lock	Support
Others
Package Contents	2 x detachable 4G antennas
	24V/0.5A passive PoE adapter
	Pole Installation Accessory
	Ethernet Cable
	Quick Installation Guide
System Requirements	Microsoft Windows 98SE/NT/2000/XP/Vista / 7 / 8 / 8.1 / 10 / 11, MAC OS, NetWare, UNIX or Linux, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Subscription with an internet service provider (for internet access)
