HD-AN100SX1000

Overview:

The sx1000l takes advantage of adata's expertise in nand flash memory technology, with better reliability and performance than ever before. Available in 2.5” standard sata form factor, the sx1000l implements advanced controller technology to achieve enhanced read/write performance.

Better capacity and speed
The sx1000l is provided with greater over-provisioning with higher efficient data compression than is often seen in general ssd controllers. Since in real-world applications most data is compressible, this means sustained performance, endurance and reliability all gain significant improvement. Sequential read speeds reach 550 mb/sec, and sequential write is as high as 500 mb/sec, with iops of 73,000 and 45,000 (maximum 4k random read and write, respectively).

Long-term reliability
The sx1000l employs static wear-leveling technology to maximize device mean time between failures (mtbf) to 1,500,000 hours, providing the long-term dependability required by high density computing and heavy load server operations.

Superior flash chips
The use of multi-level cell (mlc) nand flash memory combined with enhanced flash chip sorting allows for outstanding sustained performance, lower latency, and superior endurance. Enhanced power-loss data protection, easy monitoring of the drive quality through smart command, and flexible (user-defined) over-provisioning adjustment, all make the sx1000l a superior server solution.

Broad range of applications
The long write endurance and the 5 year warranty of the sx1000l make it extremely suitable for read-centric servers such as web and vod (video on demand) servers.

Specifications:

©2026 Respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC (//www.comx-computers.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	HD-AN100SX1000
Capacity	100GB / 200GB
Form Factor	SATA III 6Gb / sec
NAND Flash	Multi-Level Cell (MLC) NAND Flash Memory with enhanced NAND sorting methodology
Controller	LSI SandForce SF-2281
Dimensions (L x W x H)	100.25 x 70.1 x 7.0 mm
Weight	61 ±1g
Interface	SATA 6Gb / sec
Performance(Max)
Power Consumption	0.35W Idle / 0.6W Active
Operating temperature	0 °C - 70 °C
Storage temperature	-40 °C - 85 °C
Shock resistance	1500G / 0.5ms
MTBF	1,500,000 Hours
ECC Recovery	Up to 55 bits correctable per 512-byte sector (BCH)
	*varies depending on exact configuration
