• As the latest Wi Fi standard defined in IEEE 802.11, 802.11ax improves the user access capacity a nd bandwidth in high density access scenarios, reducing service latency and enhancing user experience.
• 802.11ax supports multi user multiple input multiple output (MU MIMO) on both the 2.4 GHz and 5 GHz frequency bands, allowing an AP to transmit data to a nd receive data from multiple STAs simultaneously and multiplying the utilization of radio spectrum resources.
• 802.11ax supports 1024 quadrature amplitude modulation (QAM), improving data transmission efficiency by 25% compared with 802.11ac (supporting 25 6 QAM).
• Orthogonal frequency division multiple access (OFDMA) technology enables the AP to transmit data to multiple STAs at the same time using different subcarriers, reducing latency and improving network efficiency.
• Spatial reuse (SR) technology uses ba sic service set (BSS) coloring to enable APs and STAs to distinguish overlapping BSSs, minimizing co channel interference.

• Dual radio mode: 2.4 GHz (2x2 ) + 5 GHz (2x2 ), providing a maximum rate of 575 Mbps and 1.2 Gbps, respectively, and a rate of up to 1.775 Gbps for the device. 1 x GE uplink electrical port + 1 x GE downlink electrical port.
• International 86 mm x 86 mm size: easy AP installation on an exposed or embedded junctio n box (86 mm x 86 mm) with a minimum depth of 35 mm.
• Ultra thin panel: 8 mm, slotting seamlessly into the power socket.
• Built in smart antenna: automatically adjusts the coverage direction and signal strength based on the intelligent switchover algori thm. Such capability enables the AP to flexibly adapt to the application environment changes, providing accurate and stable covera ge as STAs move. Users can enjoy full signal strength when moving around in the coverage space without any network disconnection or interruption.
• Working modes: Fit, Fat, and cloud management.
• Deployment and O&M through the HUAWEI eKit app.

Specifications:

©2026 Respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC (//www.comx-computers.co.za), however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered.
Specifications
Product Code	AP160
Dimensions (H x W x D)	86 mm x 86 mm x 42.5 mm
Weight	0.14 kg
Port type	2 x 10M/100M/1GE electrical ports
	Note - The uplink GE electrical port supports PoE input.
LED indicator	Indicates the power-on, startup, running, alarm, and fault states of the system.
Power input	PoE power supply: in compliance with IEEE 802.3af
Maximum power consumption	9.1 W
	Note The actual maximum power consumption depends on local laws and regulations.
Operating temperature	0°C to 40°C (If the altitude is in the range of 1800 m to 5000 m, the temperature decreases by 1°C every time the altitude increases by 300 m.)
Storage temperature	-40°C to +70°C
Operating humidity	5% to 95% (non-condensing)
Altitude	-60 m to +5000 m
Atmospheric pressure	53 kPa to 106 kPa
Antenna type	Built-in smart antennas
Antenna gain	2.4 GHz: 3 dBi
	5 GHz: 2 dBi
	Note 1. The preceding gain is the peak gain of a single antenna.
	2. Equivalent antenna gain after all 2.4 GHz or 5 GHz antennas are combined: 3 dBi for 2.4 GHz and 1 dBi for 5 GHz.
Maximum quantity of SSIDs on each radio	≤6
Device capacity	≤ 128
	Note The actual number of users varies according to the environment.
Maximum transmit power	2.4 GHz: 20 dBm (combined power)
	5 GHz: 20 dBm (combined power)
	Note The actual transmit power depends on local laws and regulations.
Power adjustment increment	1 dBm
Maximum number of non- overlapping channels	2.4 GHz (2.412 GHz to 2.472 GHz)
	802.11b/g - 20 MHz: 3
	802.11n
